GW instek SPS-1230 可编程开关直流电源(12V,30A,1CH)

-
Accessories: ;  User Manual x 1;  Power Cord x 1, Test Lead GTL-203*1

OUTPUT

SPS-1230
Voltage
0~12V
Current
0~30A
CONSTANT VOLTAGE OPERATION
Line Regulation < 5mV
Load Regulation < 5mV
Ripple & Noise < 5mVrms, 100mVp-p 20Hz ~ 20MHz
Recovery Time < 500μS ( 50% Load change, Minimum load 0.5A )
Temp. Coefficient < 100 ppm/°C
Output Range 0 to rating voltage continuously adjustable
CONSTANT CURRENT OPERATION
Line Regulation < 3mA
Load Regulation < 3mA
Ripple Current < 30mArms (SPS-1230)
Output Range 0 to rating current continuously adjustable (Hi/Lo range switchable)
METER
Type 3 1/2 Digit 0.39" LED Display
Accuracy ±( 0.5% of rdg + 2 digits )
INSULATION
Chassis and Terminal 20MΩ or above (DC 500V)
Chassis and AC Cord 30MΩ or above (DC 500V)
POWER SOURCE
  AC 115V/230V ±15%, 50/60Hz
DIMENSIONS & WEIGHT
  128(W) x 145(H) x 285(D)mm
Approx. 3.2kg
