GW INSTEK PEL-3041H 单通道可编程电子负载 (350W)

Voltage: 0V~800V

Current 17.5A

Power: 350W

Input Resistance: 3.24MΩ

CC Mode

Operating Range

        H 0A~17.5A

        M 0A~1.75A

        L 0A~175mA

Accuracy of Setting

        H, M ±(0.2%set+0.1%fs*1)+Vin*2/3.24MΩΩ

        L ±(0.2%set+0.1%fs)+Vin*2/3.24MΩ

        Parallel H, M, L ±(1.2%set+1.1%fs*3)

Resolution

        H 0.6mA

        M 60μA

        L 6μA

CR mode

Operating Range

        H 3.5S~60μS(285mΩ~16.6kΩ)

        M 350mS~6μS(2.85mΩ~166kΩ)

        L 35mS~0.6μS(28.5mΩ~1.66MΩ)

Accuracy of Setting

        H, M ± ±(0.5%set+0.5%fs*1)+Vin*2/3.24MΩ

        L ± ±(0.5%set+0.5%fs)+Vin*2/3.24MΩ

        Parallel (TYP) ±(1.2%set+1.1%fs*3)

Resolution

        H 60μS

        M 6μS

        L 0.6μS

CV mode

Operating Range

        H 5V~800V

        L 5V~80V

Accuracy of Setting

        H, L ±(0.2%set+0.2%fs)

        Parallel (TYP) ±(0.2%set+0.2%fs)

Resolution

        H 20mV

        L 2mV

CP mode

Operating Range

        H 35W~350W

        M 3.5W~350W

        L 0.35W~10.5W

Setting Range

        H 0W~350W

        M 0W~350W

        L 0W~10.5W

Accuracy of Setting

        H, M ± (0.6%set+1.4%fs) +Vin/3.24MΩ

Resolution

        H 10mW

        M 1mW

        L 0.1mW

Parallel mode

Capacity: 1750W

Dimensions (mm) & Weight: 213.8(W) x 124(H) x 400.5(D), 7kg
