GW INSTEK LCR-916 Gw instek LCR-916 LCR 미터 (100kHz, 0.2%)

  • 생산업체:GW INSTEK
    Model: LCR-916
    출처: Taiwan
    • 견적요구 Request a Quotation
  • 연락처
  • 재고수량: 2
    • 카트담기
    • 바로 구매하기
  •  할인 받으려면 전화하십시오

    핫라인: (+84) 969950220

    전화번호+84 (24) 62923267

-
Accessories: Shorting Cube, 2Wire Alligator Clip Set, Battery, User Manual
Options: Magnetic Hang Kit, SMD Test Probe, AC Adapter, USB Cable, 4Wire DIP Clip Set

LCR-916


TEST FREQUENCY

100Hz/120Hz/1k/10k/100kHz
 selectable


FULL SCALE
Main Display
20,000/2,000 counts selectable
Sub Display
2,000 counts
INDUCTANCE
Range
20uH ~ 20kH depends on the selected test frequency
Best Accuracy
+(0.2% rdg + 2 digits)
Resolution
0.001uH ~ 0.001kH depends on selected range
CAPACITANCE
Range
20pF ~ 20mF depends on the selected test frequency
Best Accuracy
+(0.2% rdg + 2 digits)
Resolution
0.001pF ~ 0.001mF depends on selected range
RESISTANCE
Range
20Ω ~ 200MΩ depends on the selected test frequency
Best Accuracy
+(0.2% rdg+ 2 digits)
Resolution
0.001Ω ~ 0.01MΩ depends on selected range
DC RESISTANCE
Range
200Ω ~ 200MΩ
Best Accuracy
+(0.2% rdg+ 2 digits)
Resolution
0.01Ω ~ 0.01MΩ depends on selected range
QUALITY FACTOR (Q)
Range
0.000 ~ 999
Accuracy
2 x (main parameter accuracy)
Best Resolution
0.001
DISSIPATION FACTOR (D)
Range
0.000 ~ 999
Accuracy
2 x (main parameter accuracy)
Best Resolution
0.001
PHASE ANGLE (θ)
Range
-90° ~ 90°
Accuracy
+(0.2% rdg+ 5 digits)
Resolution
0.1°
MEASUREMENT CIRCUIT

Parallel or Series selectable
AUTO LCR MODE

Automatically identifies and measures the DUT when the meter is switch on
SORTING MODE

+0.1%, +0.2%, +0.25%, +0.5%, +1.0%, +2.0%, +5.0%, +10.0%, +20.0%, +80%/-20% Selectable
OTHER FUNCTIONS

Auto range, Auto backlit, Max, Min, Data hold, Zero, Auto power off, 46 segments analogue bar
DISPLAY

LCD mono display
INTERFACE

USB
POWER SOURCE

AA Battery 1.5V x 4 or DC 5V(through AC adapter or USB cable)
DIMENSIONS & WEIGHT

95(W) × 207(H) × 52(D) mm, Approx. 630g
