GW INSTEK PSM-3004 Programmable 2 Range D.C. Power Supply (30V, 7A, 120W, 1CH)
Manufacturer: GW INSTEK Model: PSM-3004 - Request a Quotation
- Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
|
PSM-3004
|
|
|
DC OUTPUT |
|||
Low Range |
|
0~15V/7A
|
|
High Range |
|
0~30V/4A
|
|
CONSTANT VOLTAGE OPERATION |
|||
Regulation + (% of output + offset) | Load regulation < 0.01% + 2mV Line regulation < 0.01% + 2mV |
||
Ripple & Noise | < 350 μVrms/2mVpp | ||
CONSTANT CURRENT OPERATION |
|||
Regulation + (% of output + offset) | Load regulation < 0.01% + 250μA Line regulation < 0.01% + 250μA |
||
Ripple & Noise | < 2mArms | ||
RESOLUTION |
|||
Programming Voltage |
|
1mV
|
|
Programming Current |
|
0.5mA
|
|
Readback Voltage |
|
0.5mV
|
|
Readback Current |
|
0.1mA
|
|
Front Panel Voltage | 1mV | ||
Front Panel Current | 1mA ( <10a 10ma="" u="">>10A ) | ||
OVP/OCP Voltage | 10mV | ||
OVP/OCP Current | 10mA | ||
ACCURACY |
|||
Programming Voltage | 0.05% + 10mV | ||
Programming Current | 0.2% + 10mA | ||
Readback Voltage | 0.05% + 5mV | ||
Readback Current | 0.15% + 5mA | ||
OVP/OCP Voltage | 0.1% + 10mV | ||
OVP/OCP Current | 0.4% + 10mA | ||
TRANSIENT RESPONSE |
|||
< 50μsec (for output to recover within 15mV following a change in output current from full load to half load) | |||
COMMAND PROCESSING TIME |
|||
100ms | |||
VOLTAGE PROGRAMMING RESPONSE TIME (for resistive load) |
|||
Voltage Up Full Load |
|
50mS
|
|
Voltage Up No Load |
|
20mS
|
|
Voltage Down Full Load |
|
45mS
|
|
Voltage Down No Load |
|
400mS
|
|
STABILITY (% of output + offset) |
|||
Voltage | 0.02% + 1mV | ||
Current | 0.1% + 1mA | ||
MEMORY |
|||
Store/Recall 100 sets | |||
TEMPERATURE COEFFICIENT PER±(% of output + offset) |
|||
Voltage | 0.01% + 3mV | ||
Current | 0.02% + 3mA | ||
INTERFACE |
|||
Standard : RS-232C, GPIB | |||
POWER SOURCE | |||
AC100V/120V/220V±10%, 230V-6%~+10%, 50/60Hz | |||
DIMENSIONS & WEIGHT | |||
230(W) x 140(H) x 380(D)mm Approx. 10kg |
