GDM-8034 3 1/2 Digits LCD Digital Multimeter (0.5%)

DC VOLTAGE
Range 200mV, 2V, 20V, 200V, 1000V 5 ranges
Accuracy +(0.5% rdg + 1 digit)
Input Impedance 10MΩ
AC VOLTAGE
Range 200mV, 2V, 20V, 200V, 750V 5 ranges
Accuracy 40Hz ~ 500Hz+(1% rdg + 4 digits)
Input Impedance 10MΩ
DC CURRENT
Range 200μA, 2mA, 20mA, 200mA, 2A, 20A 6 ranges
Accuracy 200μA ~ 200mA+(0.5% rdg + 1 digit)
2A ~ 20A+(1% rdg + 3 digits)
AC CURRENT
Range 200μA, 2mA, 20mA, 200mA, 2A, 20A 6 ranges
Accurancy 40Hz ~ 500Hz in all ranges
200μA ~ 200mA+(1% rdg + 4 digits)
2A ~ 20A+(1.5% rdg + 2 digits)
RESISTANCE
Range 200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ 6 ranges
Accuracy 200W~ 2MΩ+(0.75% rdg + 1 digit)
20MΩ+(1.5% rdg + 5 digits)
CAPACITANCE
Range 2nF, 20nF, 200nF, 2μF, 20μF 5 ranges
Accuracy +(2% rdg + 4 digits)
Test Freq. 300Hz +5%
DIODE TEST
Test Current Max. 2.5mA
Open Voltage Max. 3.2V
CONTINUITY BEEPER
Description Buzzer sounds when conductance < 30Ω
Test Current Max. 2.5mA
Open Voltage Max. 3.2V
DISPLAY
  0.5" LCD display
POWER SOURCE
  AC 110V/220V +15%, 50/60Hz
DIMENSIONS & WEIGHT
  245(W) × 95(H) × 280(D) mm
Approx. 2kg
Detail

 download datasheet

DC VOLTAGE
Range 200mV, 2V, 20V, 200V, 1000V 5 ranges
Accuracy +(0.5% rdg + 1 digit)
Input Impedance 10MΩ
AC VOLTAGE
Range 200mV, 2V, 20V, 200V, 750V 5 ranges
Accuracy 40Hz ~ 500Hz+(1% rdg + 4 digits)
Input Impedance 10MΩ
DC CURRENT
Range 200μA, 2mA, 20mA, 200mA, 2A, 20A 6 ranges
Accuracy 200μA ~ 200mA+(0.5% rdg + 1 digit)
2A ~ 20A+(1% rdg + 3 digits)
AC CURRENT
Range 200μA, 2mA, 20mA, 200mA, 2A, 20A 6 ranges
Accurancy 40Hz ~ 500Hz in all ranges
200μA ~ 200mA+(1% rdg + 4 digits)
2A ~ 20A+(1.5% rdg + 2 digits)
RESISTANCE
Range 200Ω, 2kΩ, 20kΩ, 200kΩ, 2MΩ, 20MΩ 6 ranges
Accuracy 200W~ 2MΩ+(0.75% rdg + 1 digit)
20MΩ+(1.5% rdg + 5 digits)
CAPACITANCE
Range 2nF, 20nF, 200nF, 2μF, 20μF 5 ranges
Accuracy +(2% rdg + 4 digits)
Test Freq. 300Hz +5%
DIODE TEST
Test Current Max. 2.5mA
Open Voltage Max. 3.2V
CONTINUITY BEEPER
Description Buzzer sounds when conductance < 30Ω
Test Current Max. 2.5mA
Open Voltage Max. 3.2V
DISPLAY
  0.5" LCD display
POWER SOURCE
  AC 110V/220V +15%, 50/60Hz
DIMENSIONS & WEIGHT
  245(W) × 95(H) × 280(D) mm
Approx. 2kg
